SIMULTANEOUS DISPLAY OF BINOCULAR READINGS

The new color LCD monitor simultaneously displays the readings of both right and left eyes so that the operator can instantly observe all of the pertinent information.

WIDER MEASUREMENT RANGE

The new series' wider range allows measurements to be obtained on patients with up to ±10D of astigmatism

TOPCON'S ROTARY PRISM MEASUREMENT SYSTEM

The new 8900 series features TOPCON's exclusive Rotary Prism Technology for unmatched accuracy and reliability. The off-centered ring target is able to measure areas that may be occluded by a small diameter pupil. The prism angle enables a much wider area of the retina to be measured. As a result, the measurement image provides extremely reliable data.

FASTER MEASUREMENT

The 8900 series are among the fastest auto refractors in the world. A specially designed CPU enables the 8900 series to significantly reduce the measurement time.

SCENIC FIXATION CHART

The scenic color chart makes eye fixation easier and is adjustable in two brightness levels for optimal measuring results with either large or small pupils.

AUTO MEASUREMENT

As soon as the Autorefractor Keratometer Topcon KR-8900 is properly aligned, this innovative function initiates the measurement process and completes three readings of each eye providing that proper alignment is maintained.

CORNEA DIAMETER MEASUREMENT

Corneal diameter can be measured either during testing of the patient or later by recalling the image of the cornea on the monitor of the Autorefractor Keratometer Topcon KR-8900

  OBJECTIVE REFRACTOMETER MODE

  Sphere

-25D to +22D (0.12D/0.25D)

  Cylinder

0D to ±10D (0.12D/0.25D)

  Axis

0° to 180° (in 1° or 5° steps)

  Minimal pupil diameter

Ø2.0mm

  Target fixation

Auto fog system

  CORNEAL CURVATURE MODE

  Corneal curvature radius

5.00 to 10.00mm (0.01mm)

1.3375

67.5D to 33.75D (0.12D/0.25D)

0D to ±10D (0.12D/0.25D)

0° to 180° (in 1° or 5° steps)

3mm with 7.7mm radius

  Refraction index

  Corneal refraction

  Corneal astigmatism

  Corneal astigmatism axial

  angle

  Measuring area

  OTHER

PD measurement range

85mm max. in 1mm step

Measurement start

Auto Start/Manual (selectable)

  Measurement display

Color LCD Monitor

  Measurement recording

Built-in printer (Up to 10 measurements of each eye can be stored in memory)

  Alignment

5" LCD

  Vertex distance

0, 12.0 and 13.75mm (selectable)

  Energy saving

Automatic Power Saver Mode when left unused for 10 minutes

  Power supply

100-120,220-240V AC, 50/60Hz, 75VA

  Output

RS-232C / USB1.1

  Weight

20.0kg

  Dimensions

275(W) x 475(D) x 450(H)mm
