Phoropter Reichert Illuminated

Reichert Illuminated

The Phoropter reichert Illuminated:

You work hard to help improve your patient's eye sight, but who is looking out for yours? No more straining to read the dials in a dark room. With lighted sphere, cylinder power, and the cylinder axis scales, you can put the pen light down and leave the lights off through the entire refraction.

In the phoropter reichert Illuminated the light is provided by cool-running, energy efficient LEDs (Light Emitting Diodes) that light only what you need to see without affecting the darkened refracting environment. The best of all they are maintenance free so you'll never need to change a light bulb.

This phoropter reichert Illuminated is the latest in a series of Reichert refracting instruments that began with the invention of the Phoropter instrument. It incorporates refinements that represent more than 70 years of experience in working with doctors and thousands of instruments installed. It embodies the characteristics that doctors need and want most, including accuracy, speed, ease, patient comfort, and reliability.


Features for phoropter reichert illuminated

Typical Reichert reliability

The Ultramatic Phoropter Reichert Illuminated is engineered and built to the high standards that have made Reichert refracting instruments famous for longevity during the past 70 years. Corrosion-resistant materials, precision machining, skilled workmanship, rigid inspection, "life testing", and Reichert service mean that the Ultramatic Illuminated will provide dependable long-term performance.

Unique, synchronized cross cylinder saves time by simplifying a cumbersome procedure

Consider the number of cross cylinder axis settings you make during a typical refraction, and the time they cost you. The Ultramatic Illuminated eliminates these settings to streamline your procedure and save valuable time. When you change cylinder axis, the cross cylinder automatically rotates to a corresponding axis. You read a single scale once at the conclusion of the test.

Ful-Vue convergence provideds the widest field of view for maximum accuracy

Completely overlapping fields during near testing mean precision measurement. With the flip of two levers, the entire optical system is converged.
Convergence combines with the large main aperture to provide the widest binocular field of view of any refracting instrument. The patient looks through the optical centers of the instrument lens system, insuring completely overlapping fields. The ultimate in clinical accuracy

More helpful features that increase accuracy, speed, and ease

Choice of minus or plus system. The cylinder axis control is concentric with the cylinder power knob. The control knob rotates a full 360 degrees and is surrounded by the axis scale. An axis reference scale at the main aperture speeds retinoscopy.
Convenient P.D. adjustment. Simply turn a knob on either side for velvet smooth adjustment. The easy-to-read scale is in 1 mm graduations.

Specifications Range for phoropter reichert Illuminated
Sphere -19.00D to + 16.75D
Cylinder Power 0.00D to 6.00D
Cylinder Axis° 360° (Double 0°-180° scale)
Cross Cylinder ± 0.25
Prism 0 to 20
P.D. 48mm to 75mm
Vertex Distance 13.75mm (normal)
Reading Distance 5" to 28"
Auxiliary Dial 10 lenses plus 2 open apertures


Contact us for Price*
